Master Incalzitoare / Incalzitoare Electrice / Radiatoare infrarosu
/ Incalzitoare electrice (aeroterme)
/ Incalzitoare electrice (aeroterme)
___________________________________________________________________________________________
Caracteristici TS 3A HALL 1500 HALL 3000 HALL 3000 C
___________________________________________________________________________________________
Capacitate: kW 0,8-1,6-2,4 1,5 1,5-3 1,5-3
Btu/h 2.700-8.200 5.100 5.100-10.200 5.100-10.200
Kcal/h 690-2.070 1.290 1.290-2.580 1.290-2.580
Curent maxim absorbit: A 10,5 6,5 13 13
Alimentare: V/Hz 230-240/50 230-240/50 230-240/50 230-240/50
Dimensiuni H x SZ x M: cm 38x24x46 54x25x32 55x34x64 80x28x53
Greutate net: kg 7,4 4,8 12 14
Greutate brut: kg 8 5,7 13 15
Palet (buc): 36 36 12 16
___________________________________________________________________________________________
Caracteristici TS 3A HALL 1500 HALL 3000 HALL 3000 C
___________________________________________________________________________________________
Capacitate: kW 0,8-1,6-2,4 1,5 1,5-3 1,5-3
Btu/h 2.700-8.200 5.100 5.100-10.200 5.100-10.200
Kcal/h 690-2.070 1.290 1.290-2.580 1.290-2.580
Curent maxim absorbit: A 10,5 6,5 13 13
Alimentare: V/Hz 230-240/50 230-240/50 230-240/50 230-240/50
Dimensiuni H x SZ x M: cm 38x24x46 54x25x32 55x34x64 80x28x53
Greutate net: kg 7,4 4,8 12 14
Greutate brut: kg 8 5,7 13 15
Palet (buc): 36 36 12 16
___________________________________________________________________________________________
__________________________________________________________________________________________
Caracteristici B 2 B 3 B 5 B 9 B 15 B 22
__________________________________________________________________________________________
Capacitate: kW 1-2 1,5-3 2,5-5 4,5-9 7,5-15 11-22
Btu/h 3.440 - 5.160 - 5.600 - 15.480 - 25.800 - 37.840 -
- 6.800 - 10.320 - 17.200 - 30.960 - 51.600 - 75.680
Kcal/h 860 - 1.290 - 2.150 - 3.870 - 6.450 - 9.460 -
- 1.720 - 2.580 - 4.300 - 7.740 - 12.900 - 18.920
Curent maxim absorbit: A 8,6 13 7,2 13 21,7 32
Alimentare: V/Hz 230/50 230/50 400/3-50 400/3-50 400/3-50 400/3-50
Volum aer circulat: m³/h 350 400 450 780 990 2.200
Dimensiuni H x SZ x M: cm 22x24x43 29x28x43 29x36x41 34x44x54 38x48x53 52x58x64
Greutate net: kg 4 6 7 11 16 23
Greutate brut: kg 5 7 9 13 19 26
__________________________________________________________________________________________
Caracteristici B 2 B 3 B 5 B 9 B 15 B 22
__________________________________________________________________________________________
Capacitate: kW 1-2 1,5-3 2,5-5 4,5-9 7,5-15 11-22
Btu/h 3.440 - 5.160 - 5.600 - 15.480 - 25.800 - 37.840 -
- 6.800 - 10.320 - 17.200 - 30.960 - 51.600 - 75.680
Kcal/h 860 - 1.290 - 2.150 - 3.870 - 6.450 - 9.460 -
- 1.720 - 2.580 - 4.300 - 7.740 - 12.900 - 18.920
Curent maxim absorbit: A 8,6 13 7,2 13 21,7 32
Alimentare: V/Hz 230/50 230/50 400/3-50 400/3-50 400/3-50 400/3-50
Volum aer circulat: m³/h 350 400 450 780 990 2.200
Dimensiuni H x SZ x M: cm 22x24x43 29x28x43 29x36x41 34x44x54 38x48x53 52x58x64
Greutate net: kg 4 6 7 11 16 23
Greutate brut: kg 5 7 9 13 19 26
__________________________________________________________________________________________
